product features:
Contamination on vehicles, packages or personell enter the facillity could be a potentiall threat the hugh economical consequenses. The best protection to this threat is to measure at the gates of your perimeter. In addition there might also be of interest to classify the radionuclide material. This is best done with a spectroscopic solution with real-time identification.
• Highly Sensitive Large Area Plastic Scintillation Detectors
• Microprocessor Based Electronics
• Audible and Visual Alarm Indicators Dynamic Alarm Circuit for Optimal Sensitivity
• Monitoring of trucks, pedestrians or trains
• Designed to detect nuclear materials used in weapons of mass destruction (WMD)
• Extremely fast measurement processing
• Surveillance around the clock
• Fast, precise and robust
• Simple, safe and intuitive operation
• Configuration to suit application
• Minimum false alarm rate
• Customer-specific system configuration
• Minimum false alarm rate
• Approved in many applications
• Database for measurement results
• Extendable with additional cameras, barriers, traffic lights or lighting
INDICATED USE: Radiation monitoring
SYSTEM OPERATION: Typically located at the scale/entrance area. The system will continuously monitor incoming materials for radiation.
DETECTORS: thick shielded NaI(Tl) scintillation detectors in NEMA 4x weather tight enclosures.
DISPLAY: 4 digit LED display with 0.8"(2 cm) high characters
DISPLAY UNITS: kCPM
STATUS:(green light) indicates the instrument is functioning properly
LOW ALARM: Indicated by yellow LOW ALARM light and slow beep (1 per second) audible tone (can be set at any point from 0.0 - 9999)
HIGH ALARM: Indicated by red HIGH ALARM light and slow beep (4 per second) audible tone (can be set at any point from 0.0 - 9999)
LOW BAT: (yellow) indicates less than 2 hours of battery power remaining.
OVERLOAD: Senses detector saturation (indicated by display reading "-OL-") OVERRANGE: Indicates radiation field being measured has exceeded counting range of instrument (indicated by display reading "----")
REMOTE(optional): Allows for connection of red strobe for remote indication of an alarm
BATTERY CHARGER: Battery is continuously trickle charged when instrument is connected to line power and turned on
TEMPERATURE RANGE: -20 degrees F(-29 degrees C) to 140 degrees F(60 degrees C)
